Industrial Stone Wool for Pipework, Ductwork and Process Equipment

TSCL strip, TSD board and TSC board for pipework, vessels, ductwork, air-handling units and plant rooms.

Automated plant floor with white robotic palletizing arms and blue roller conveyors behind orange safety railings.

What this element needs

Standards this element is specified against
StandardWhat it coversDeclared and measured values
EN 13162:2012+A1:2015Specifies requirements for factory made mineral wool products, with or without facings or coatings, for the thermal insulation of buildings. A harmonised standard under Regulation (EU) No 305/2011.
EN 13501-1:2018Sets the reaction-to-fire classes of construction products from the results of the EN reaction-to-fire tests.
EN 12667:2001Method for measuring thermal resistance and thermal conductivity with a guarded hot plate or a heat flow meter.

Grades for this element

Models for this element, with the CE window, DoP and measured λ of each grade
Model CodeDensity (kg/m³)Thickness, factory range (mm)Thickness, CE window (mm)DoPλ measured, W/(m·K)
Taishi® Marine Insulation Stone Wool Board
TSC808030–15050–200TAISHI-DoP-EN13162-080 Public0.031 WSW 25100046
TSC12012030–15050–200TAISHI-DoP-EN13162-120 Issued on request0.034 WSW 25100048
TSC16016030–15050–150TAISHI-DoP-EN13162-160 Issued on request0.034 WSW 25100050
TSC20020030–150
TSCL12012048.5–10050–200TAISHI-DoP-EN13162-120 Issued on request0.034 WSW 25100048
TSCL15015048.5–100
TSCL20020023–100
TSCL22022023–100
Taishi® Multipurpose Stone Wool Board
TSD404030–20050–200TAISHI-DoP-EN13162-040 Issued on request0.035 WSW 25100052
TSD606030–20050–200TAISHI-DoP-EN13162-060 Public0.032 WSW 25100053
TSD808030–20050–200TAISHI-DoP-EN13162-080 Public0.031 WSW 25100046
TSD10010050–10050–200TAISHI-DoP-EN13162-100 Issued on request0.031 WSW 25100045
TSD12012050–10050–200TAISHI-DoP-EN13162-120 Issued on request0.034 WSW 25100048
TSD14014050–10050–200TAISHI-DoP-EN13162-140 Issued on request0.034 WSW 25100049
  • CE certificate 2649-CPR-26000401 covers 40, 60, 80, 100, 120, and 140 kg/m³, at thicknesses within 50–200 mm.
  • CE certificate 2649-CPR-26000401 covers 160 kg/m³, at thicknesses within 50–150 mm.

Specifying and fitting

Pipework, vessels and tanks

Lamella strip wraps large pipes, vessels and tanks with its fibres perpendicular to the surface. Your engineer sets the thickness from the heat-loss and surface-temperature targets at the operating temperature.

Ductwork and air-handling units

Board lines or wraps supply and return ducts, air-handling units and plenum walls for thermal and acoustic treatment. The mechanical engineer sets the thickness for the duct's heat-gain and noise targets.

Equipment housings and plant rooms

Board lines the housings of pumps, compressors and generators and the walls of plant rooms. TSD serves mixed sites where one board covers several uses.

Rock Wool vs Glass Wool: Max service temperature

Papers by market

Certificates held for this element, by market
MarketWe hold
European Union
  • CE Conformity (EN 13162) 2649-CPR-26000401
United Kingdom
  • CE Conformity (EN 13162) 2649-CPR-26000401
Israel
  • CE Conformity (EN 13162) 2649-CPR-26000401
Gulf: Saudi Arabia
  • CE Conformity (EN 13162) 2649-CPR-26000401
Russia and CIS
  • GOST Fire Safety (Russia) РОСС RU.32079.04СПБ1.ОС14.64027

Evidence

Test reports behind these grades
ReportLaboratoryMethodResultGrades
WSW 25100045–25100053CTC Nanjing Guocai Testing Co., Ltd.EN 12667:2001Thermal conductivity at 10 °C mean for each grade, measured on a single batch.40, 60, 80, 100, 110, 120, 140, 160, and 180
XJ2026B03D02237GB/T 19686-2015Conforms to GB/T 19686-2015 in full. Reaction to fire class A (A1) under GB 8624-2012.80
WSW 25030179GB/T 19686-2015Conforms to GB/T 19686-2015 in full. Reaction to fire class A (A1) under GB 8624-2012. Three-star green building material under T/CECS 10032-2019.100
SHFS2401000125FFSGS-CSTC Standards Technical Services (Shanghai) Co., Ltd.EN 13162:2012+A1:2015Reaction to fire class A1 under EN 13501-1:2018, with measured values for the other properties.140
SHFS2401000126FFSGS-CSTC Standards Technical Services (Shanghai) Co., Ltd.EN 13162:2012+A1:2015Reaction to fire class A1 under EN 13501-1:2018, with measured values for thermal conductivity and compressive stress.80
251202026SHF-001IntertekEN ISO 1182:2020Non-combustibility test data. Read it with the classification report for the same density.40
251202026SHF-002IntertekEN ISO 1716:2010Gross heat of combustion test data. Read it with the classification report for the same density.40
251202026SHF-003IntertekEN 13501-1:2018Classified A1 under EN 13501-1:2018.40
251202026SHF-004IntertekEN ISO 1182:2020Non-combustibility test data. Read it with the classification report for the same density.180
251202026SHF-005IntertekEN ISO 1716:2010Gross heat of combustion test data. Read it with the classification report for the same density.180
251202026SHF-006IntertekEN 13501-1:2018Classified A1 under EN 13501-1:2018.180

All test reports, with laboratories and accreditation marks
